Buzzer BMC1265

Parts shall be measured under one condition (temperature: 5~35 ℃, humidity: 45% ~ 85% R.H., atmospheric pressure: 860 ~ 1060hPa), unless standard conditions (temperature: 25±3 ℃, humidity: 60±10%R.H. atmospheric pressure: 860 ~ 1060hPa) are adjusted.

1. Test Conditions Product Test Conditions: Temperature: 5~35 ℃, Humidity: 45% ~ 85% R.H., Air Pressure: 860 ~ 1060hPa. Standard test conditions: temperature: 25±3 ℃, humidity: 60±10%R.H. air pressure: 860~1060hPa1 rated voltage 5VDC2 working voltage 4-7VDC3 rated current Max.30mA,at5VDC4 output sound pressure Min.82dB,at5VDC5 resonance frequency 2700±300 Hz6 tone Continuous7 working temperature (℃)-20 ℃ ~ +70
1. Test Conditions Product Test Conditions: Temperature: 5~35 ℃, Humidity: 45% ~ 85% R.H., Air Pressure: 860 ~ 1060hPa. Standard test conditions: temperature: 25±3 ℃, humidity: 60±10%R.H. air pressure: 860~1060hPa1 rated voltage 5VDC2 working voltage 4-7VDC3 rated current Max.30mA,at5VDC4 output sound pressure Min.82dB,at5VDC5 resonance frequency 2700±300 Hz6 tone Continuous7 working temperature (℃)-20 ℃ ~ +70
Online message

Keywords: buzzer | horn | materialized film

Product Description

1. Technical Parameter
Measuring condition

Part shall be measured under a condition (Temperature: 5~35℃, Humidity: 45% ~ 85%R.H., Atmospheric pressure: 860 ~ 1060hPa) unless the standard condition (Temperature: 25±3℃, Humidity: 60±10%R.H. Atmospheric pressure: 860 ~1060hPa) is regulated to measure.

1 Rated Voltage 5Vo-p
2 Operating Voltage 3-7VDC
3 Rated Current Max.30mA, at 5VDC
4 Sound Output at 10cm Min.85dB, at 5VDC
5 Tone Continuous
6 Resonant Frequency 2700±300Hz
7 Operating Temperature -20- +70℃
8 Store Temperature -30 - +80℃
9 Net Weight Approx 1.5g
10 RoHS Yes

2. Dimensions Unit: mm

*Unit: mm; Tolerance: ±0.5mm Except Specified
*Housing Material: Black PBT

3. Electrical And Acoustical Measuring Condition

Recommended Test Circuit

Recommended Setting

4.Reliability Test

After any following tests the part shall meet specifications without any degradation in appearance and performance except SPL. SPL shall not deviate more than -10 dB from the initial value
a)Ordinary Temperature Life Test
The part shall be subjected to 96 hours at 25±10℃. Input rated voltage Resonant frequency, 1/2 duty Square wave.
B )High Temperature Test
The part shall be capable of with standing a storage temperature of +85℃ for 96 hours.
c)Low Temperature Test
The part shall be capable of with standing a storage temperature of -40℃ for 96 hours.
d)Humidity Test
Temperature:+40℃±3℃ Relative Humidity:90%~95% Duration: 48 hours and expose to room temperature for 6 hours
e)Temperature Shock Test
Temperature:60℃ /1hour→ 25℃/3hours→-20℃/1hour→ 25℃/3hours (1cycle) Total cycle: 10 cycles
f)Drop Test
Standard Packaging From 75cm(Drop on hard wood or board of 5cm thick, three sides, six plain.)
g)Vibration Test
Vibration:1000cycles /min. Amplitude:1.5mm, Duration: 1 hour in each 3 axes

Note:

As this product is not protected from foreign material entering, please make sure that any foreign materials (e.g. magnetic powder, washing solvent, flux, corrosive gas) Do not enter this product in your production processes. The functional degradation (e.g. spl down) may occur if foreign material enter it.

5.Packing

packing requirements

12 foam box, foam material number: F6-712,1000pcs a pile; 5 piles/box; 5000 pcs/box
carton material number: F6-003; Outer box size 50*41 * 25cm

shipping mark requirements

inner box:

according to customer order

outer box:

by customer order
